Product Description
HIOSO HA7304 4 PORT EPON OLT FREE 4PX 20+++ 7DB
* Dikemas untuk solusi FTTH yang berbeda oleh Kosmoswave.
* OLT adalah elemen jaringan Fiber To The Home (FTTH) yang menyediakan antarmuka PON menuju core IP/Ethernet dan jaringan operasi
Parameter Specifications
HA7304 Standalone 4PON OLT
Supply 4 SFP PON ports, 2 1000M SFP ports, 2 1000M RJ45 uplink ports
Each PON port support 1:64 split ratio, total 256 ONUs access
Distance can reach 20km under 1:32 split ratio
Apply for town,village fiber network and surveillance, apply for FTTX network
To transmit IP phone, data IPTV and other IP services acceshios
Operating wavelength 1310(RX) /1490(TX)
Optical power +2.5 ~ +7dBm
Receiving sensitivity -30dBm
Max distance 20km
Max splitter ratio 1:64
Capacity 4 PON, maximum 256pcs ONU
MAC 8k
Uplink port 2 SFP ports + 2 TP ports
PON port 4 SFP PON ports
Control port
1 10/100/1000M RJ45 port
1 Console(RJ45), to debug the device
1 USB port
MTBF 100,000 hours
EPON traits
Support IEEE802.3ah
Support DBA with minimum1Kbps granularity adjustable
Support 1Gbps up link and down link symmetrical bandwidth
Support AES-128 encryption to each Logical Link Identifier
Support powerful OAM function, implement telnet management, maintenance and upgrade
Support auto discovery and auto register of ONU (real-time operation)
Protocols supported=
Support IEEE802.3?IEEE802.3u?IEEE802.3ab?IEEE802.3z
Support IEEE802.1Q VLAN?IEEE802.1d Spanning Tree
Support IEEE 802.1P QoS?IEEE802.3X Flow Control
Support IEEE802.3ad Trunk?IEEE802.1W RSTP
Network management=
Support GUI management based on SNMP
Support WEB and Telnet GUI management based on CLI
Other functions=
Support 1GMPv1/v2 protocol report, query and leave message mouse
Support ONU remote configure and upgrade
Support real-time alarm detection, accurate fault location
Support the alarm information sent to the mailbox, support SMS alarm
